Air Conditioner AC Contactors
Application Range Our Air conditioner AC Contactors and auxiliary switches are designed to provide maximum dependability with life cycles exceeding 250,000 electrical and 1,000,000 mechanical. Once mounted, their performance remains strong, meeting the ARI 780/790 standard. You can rely on our...
Description
Application Range
Our Air conditioner AC Contactors and auxiliary switches are designed to provide maximum dependability with life cycles exceeding 250,000 electrical and 1,000,000 mechanical. Once mounted, their performance remains strong, meeting the ARI 780/790 standard. You can rely on our products to offer you the utmost reliability.
This device comprises of plastic housing, stationary terminals, an actuator for positioning, and a magnet/coil assembly. It is built with superior endurance and insulation capabilities that surpass those of regular contactors.
Our CJX9 series is manufactured with precision using engineered compounds, making it a top choice for even the most challenging applications. Its internal construction is specially designed to deliver exceptional mechanical durability, ensuring long-lasting performance.
Advantage
Our product boasts superior materials, with premium silver alloy contacts that guarantee a long lifespan. Our shock-resistant actuator arms provide exceptional mechanical durability, while our durable molded plastic housing ensures your product's longevity. With industry-standard mounting plates and a compact, easy-to-install design, our product is the perfect choice for any project. Trust us to deliver the quality and performance you deserve.
Options
We offer a diverse selection of contactor configurations to meet your specific electrical needs. Our contactors are available in 1, 2, 3, and 4 pole configurations, with AC coil voltages of 24, 120, 240, and 480 volts. We provide a wide range of electrical ratings and offer screw, box, or pressure plate connections, depending on your application requirements. Our contactors are designed with a NEMA mounting base for easy installation. Trust us to provide reliable and efficient contactor solutions for your electrical systems.
NO/NC End Switch Kits
Technical Specifications
Our electrical contactor has a rating of 20 to 90 amps and is built to last. With a life rating of 100,000 to 25,000 cycles and an electrical coil rating of 24 to 600VAC, this contactor is a reliable choice for your electrical needs. We also offer a variety of options to ensure that you get the right fit for your specific application. Whether you need a contactor with a higher amp rating or a different coil rating, we've got you covered. Choose our electrical contactor for a dependable solution to your electrical requirements.
APPLICATIONS
AC contactors are primarily utilized in the industry, particularly in refrigeration, air conditioning, and heating systems. These devices are specifically designed to cater to the needs of these industries. With their versatile functionality and reliable performance, AC contactors play a vital role in ensuring efficient operation and temperature regulation in various cooling and heating appliances. Whether it's maintaining the desired temperature in a refrigeration unit or controlling the airflow in an air conditioning system, AC contactors are the go-to solution. Their widespread use in these applications highlights their critical role in the industry.
Other applications include:
Food service equipment
Vending machines Hoists
Compressors Welding machines
Pumps Power supplies
Cranes Lighting
Item Specifications
Type:SPDT at position2 | ||||
Field Modification Kits | ||||
Description | Poles | Contactor FLA | Auxiliary Contacts | Catalog Number |
Snap-on Side Mounted Auxiliary Contacts | 2P-3P | 25-26 | 1NO | HCACRO |
1NC | HCACRC | |||
1NO ＆1NC | HCACR6 | |||
2NO | HCACR7 | |||
2NC | HCACR8 | |||
1SPDT | HCD36098001 | |||
2SPDT | HCD36098003 | |||
2P-3P | 75-90 | 1NO | HCD22125001 | |
1NC | HCD22125002 | |||
1SPDT | HCCE42SPDT | |||
Mechanical Interlock | 2P-3P | 25-60 | - | HCD70035001 |
Application Range
AC Contactors for air conditioners, refrigeration, resistive heating, lighting, and other installations in commercial settings are ideal due to their cost-effectiveness and exceptional performance. These contactors offer a reliable solution for various applications that require a high-performance contactor at an affordable price.
Products Details
Model | 5P-30A-24V | -1.5P-30A-120V | .5P-30A-240V | .5P-40A-24V | .5P-40A-120V | 5P-40A-240V |
FLA | 30 | 30 | 30 | 40 | 40 | 40 |
Poles | 1 | 1 | 1 | 1 | 1 | 1 |
Resistive Amps | 40 | 40 | 40 | 50 | 50 | 50 |
Coil Voltage | 24 | 120 | 240 | 24 | 120 | 240 |
Hertz | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Locked Rotor Amos 240/480/600 | 180/150/120 | 180/150/120 | 180/150/120 | 240/200/160 | 240/200/160 | 240/200/160 |
Electrical Contact Ratings:20A-90A electrical coil ratings:24-600V life rating,100000＆250000 cycle options.
Options:1,2,3,4pole fits 24,120,240 and 480VAC coils wide range of electrical ratings screw,box or oressure connections NEMA mounting base.NO/NC end switch kits.
Terminations:#10-32 screw-20,25＆30FLAModels,Box Lug-40,50,60,75＆90FLA Models
Temperature Range:-40℉ to+150℉/-40℃to+65℃
Specification
MODEL | FLA(A） | FLA(A） | FLA(A） | FLA(A） | FLA(A） | Phase | Resistive AMPS RATING |
CJX9 | 480Vac | 600Vac | 277Vac | 240Vac | / | 277vac | |
20 | 100 | 80 | 120 | 120 | 1 | 30 | |
25 | 125 | 100 | 150 | 150 | 1 | 35 | |
30 | 150 | 120 | 180 | 180 | 1 | 40 | |
40 | 200 | 160 | 240 | 240 | 1 | 50 | |
Mechanical Life:1000000Times | Electrical LIfe:250000Times | ||||||
Products Details
Model | 2P-30A-24V | 2P-30A-120V | 2P-30A-240V | 2P-40A-24V | -2P-40A-120V | -2P-40A-240V |
FLA | 30 | 30 | 30 | 40 | 40 | 40 |
Poles | 2 | 2 | 2 | 2 | 2 | 2 |
Resistive Amps | 40 | 40 | 40 | 50 | 50 | 50 |
Coil Voltage | 24 | 120 | 240 | 24 | 120 | 240 |
Hertz | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Locked Rotor Amos 240/480/600 | 180/150/120 | 180/150/120 | 180/150/120 | 240/200/160 | 240/200/160 | 240/200/160 |
Electrical Contact Ratings:20A-90A electrical coil ratings:24-600V life rating,100000＆250000 cycle options.
Options:1,2,3,4pole fits 24,120,240 and 480VAC coils wide range of electrical ratings screw,box or oressure connections NEMA mounting base.NO/NC end switch kits.
Terminations:#10-32 screw-20,25＆30FLAModels,Box Lug-40,50,60,75＆90FLA Models
Temperature Range:-40℉ to+150℉/-40℃to+65℃
Specification
MODEL | FLA(A） | FLA(A） | FLA(A） | FLA(A） | FLA(A） | Phase | Resistive AMPS RATING |
480Vac | 600Vac | 277Vac | 240Vac | / | 277vac | ||
CJX9 | 20 | 100 | 80 | 120 | 120 | 1 | 30 |
25 | 125 | 100 | 150 | 150 | 1 | 35 | |
30 | 150 | 120 | 180 | 180 | 1 | 40 | |
40 | 200 | 160 | 240 | 240 | 1 | 50 | |
50 | 240 | 200 | 240 | 300 | 3 | 65 | |
60 | 300 | 240 | 240 | 360 | 3 | 75 | |
75 | 300 | - | 300 | 450 | 3 | 90 | |
90 | 360 | - | 360 | 540 | 3 | 120 | |
30 | 150 | 120 | 180 | 180 | 3 | 40 | |
40 | 200 | 160 | 240 | 240 | 3 | 50 | |
Mechanical Life:1000000Times | Electrical LIfe:250000Times | ||||||
Products Details
Model | 3P-30A-24V | 3P-30A-120V | 3P-30A-240V | 3P-40A-24V | 40A-120V | 40A-240V |
FLA | 30 | 30 | 30 | 40 | 40 | 40 |
Poles | 3 | 3 | 3 | 3 | 3 | 3 |
Resistive Amps | 40 | 40 | 40 | 50 | 50 | 50 |
Coil Voltage | 24 | 120 | 240 | 24 | 120 | 240 |
Hertz | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
Locked Rotor Amos 240/480/600 | 180/150/120 | 180/150/120 | 180/150/120 | 240/200/160 | 240/200/160 | 240/200/160 |
Electrical Contact Ratings:20A-90A electrical coil ratings:24-600V life rating,100000＆250000 cycle options.
Options:1,2,3,4pole fits 24,120,240 and 480VAC coils wide range of electrical ratings screw,box or oressure connections NEMA mounting base.NO/NC end switch kits.
Terminations:#10-32 screw-20,25＆30FLAModels,Box Lug-40,50,60,75＆90FLA Models
Temperature Range:-40℉ to+150℉/-40℃to+65℃
Specification
MODEL | FLA(A） | FLA(A） | FLA(A） | FLA(A） | FLA(A） | Phase | Resistive AMPS RATING |
480Vac | 600Vac | 277Vac | 240Vac | / | 277vac | ||
CJX9 | 20 | 100 | 80 | 120 | 120 | 3 | 30 |
25 | 125 | 100 | 150 | 150 | 3 | 35 | |
30 | 150 | 120 | 180 | 180 | 3 | 40 | |
40 | 200 | 160 | 240 | 240 | 3 | 50 | |
50 | 240 | 200 | 240 | 300 | 3 | 65 | |
60 | 300 | 240 | 240 | 360 | 3 | 75 | |
75 | 300 | - | 300 | 450 | 3 | 90 | |
90 | 360 | - | 360 | 540 | 3 | 120 | |
Mechanical Life:1000000Times | Electrical LIfe:250000Times | ||||||
